Product Parameters
| Category | Parameter Details |
|---|---|
| Model Number | 63-15x50 |
| Optical Parameters | |
| - Magnification | 15x |
| - Objective Diameter | 50mm |
| - Field of View | ≥4° (Field width ≥69.8m at 1000m distance) |
| - Exit Pupil Distance | 18mm (Suitable for eyeglass wearers) |
| - Exit Pupil Diameter | 4mm |
| - Eyepiece Diameter | 22mm |
| Functional Features | |
| - Rangefinder | Crosshair reticle plate (for distance estimation) |
| - Prism Material | BAK4 optical glass (High light transmittance, no vignetting) |
| - Eyecup Type | Rubber fold-down (Retractable for comfort adjustment) |
| - Coating Technology | Broadband green film (Main coating, ≥98% transmittance at 550nm) + Blue film (Auxiliary AR coating, ≤1.5% reflectance at 450nm) |
| Environmental Resistance | |
| - Anti-Fog | Yes (Nitrogen purged, dew point ≤-40°C) |
| - Waterproof | Submersible up to 1.5m depth for 30 minutes (IPX8 compliant) |
| - Shockproof | Passed 1m drop test onto 1m-wide, 20cm-thick sand layer |
Product DetailsProduct Details
 |
 |
| High Quality | Easy to Use |
 |
 |
| Industrial Handling | Military Handling |
2.Magnification Selection
3.Binocular Coatings
4.Waterproof Ratings
5.Suitable Scenarios
